LX Electric Suspension Crane

Product Introduction：

　Model LX Electric Single-girder Suspension Crane is designed and manufactured in accordance with JB/T 2603-1994. It is supportingly used with CD, MD and other types of electric hoists, forming a rail-running light and small-sized crane.Its applicable lifting capacity is 0.5~5t, applicable span 3~16m, and the operating ambient temperature ranges from -30℃ to 40℃.This product is a general-purpose crane, mostly applied in machinery manufacturing and assembly, warehouses, caverns and other occasions.The crane is mainly composed of four parts: bridge frame (metal structure), electric hoist, travelling mechanism and electrical equipment.Lifting Capacity Q（t）0.5；1；2；3；5Span LK（m）3~16Crane Travelling Mechanism运行速度V（m/min）2030减速比i28.220电动机ZDY12-4 N=2×0.4KW m=1380r/min电动葫芦型式CD或MD起升速度V1（m/min）8或8/0.8起升高度H（m）6、9、12、18、24、30运行速度V2（m/min）20、30电动机锥形鼠笼型工作级别中级（JC=25%）电源3相 50HZ 380V车轮工作直径（mm）Φ130轨道工字钢（GB706-65）120a~145c

Get a Quote

Online Consultation

PRODUCT DETAILS
Application area
Related Recommendations

PRODUCT DETAILS

This product is a general-purpose crane, mostly applied in machinery manufacturing and assembly, warehouses, caverns and other occasions.The crane is mainly composed of four parts: bridge frame (metal structure), electric hoist, travelling mechanism and electrical equipment.

Lifting Capacity Q（t）	0.5；1；2；3；5
Span LK（m）	3~16
Crane Travelling Mechanism	运行速度V（m/min）	20	30
	减速比i	28.2	20
	电动机	ZDY12-4 N=2×0.4KW m=1380r/min
电动葫芦	型式	CD或MD
	起升速度V1（m/min）	8或8/0.8
	起升高度H（m）	6、9、12、18、24、30
	运行速度V2（m/min）	20、30
	电动机	锥形鼠笼型
工作级别	中级（JC=25%）
电源	3相 50HZ 380V
车轮工作直径（mm）	Φ130
轨道工字钢（GB706-65）	120a~145c
